5 Years Warranty 35W LED Well Glass CIP-312-35-57-SL-CP-NBK Make: Crompton

5 Years Warranty 35W LED Well Glass CIP-312-35-57-SL-CP-NBK Make: Crompton About

Achieve superior industrial lighting with the Crompton 35W LED Well Glass Luminaire (Model: CIP-312-35-57-SL-CP-NBK). This efficient and durable lighting solution is ideal for use in cement plants, power plants, steel plants, material handling areas, and semi-outdoor spaces.

With a sturdy die-cast aluminum housing and a clear polycarbonate cover, this luminaire is designed for demanding environments. The IP66-rated protection ensures resistance to dust and water, while the high luminous efficacy of over 120 lumens per watt guarantees optimal illumination with low energy consumption.

Key Features:

• Energy Efficiency: High luminous efficacy of >120 lumens per watt at 5700K.
• Durable Design: Robust die-cast aluminum housing with matt-black powder coating.
• Reliable Protection: IP66-rated for challenging industrial environments.
• Surge Protection: Integrated 4KV surge arrestor for enhanced safety.
• Easy Installation and Maintenance: Cradle with an eye bolt for mounting and replaceable driver.

Applications:
Recommended for industrial environments such as cement plants, power plants, steel plants, and outdoor/semi-outdoor areas.

Technical Specifications:

1. Electrical Parameters:

   • Rated Voltage: 240V
   • Frequency: 50Hz 3%
   • Operating Voltage Range: 120-270V
   • Power Consumption: 35W
   • Current: 0.153A
   • Power Factor: >0.95
   • Total Harmonic Distortion (THD): <10%

2. Optical Parameters:

   • Correlated Color Temperature (CCT): 5700K
   • Color Rendering Index (CRI): 70
   • Luminous Efficacy: >120 lumens/watt

3. Construction:

   • Housing: Pressure die-cast aluminum with matt-black powder coating
   • Cover: Clear polycarbonate
   • Internal Wiring: PVC multistrand copper wire

4. Protection and Safety:

   • Surge Arrestor: Inbuilt 4KV in driver
   • Ingress Protection: IP66

5. Installation Details:

   • Mounting: Cradle with an eye bolt
   • Maintenance: Replaceable driver

Ordering Code: CLI300400-A2

Choose the Crompton 35W LED Well Glass Luminaire for efficient and reliable industrial lighting solutions!
